Red 0.56 inch Mini Digital Voltmeter DC 0-30V Voltage Panel Meter For 6V 12V Electro mobile Motorcycle Car 3 Wires Products

Measuring range 0.00V-30.0V

Power supply range red DC4.50-30.0V, green DC4.70-30.0V, blue DC5.00-30.0V

Maximum input DC30.0V. Note: Input voltage higher than 30V may be permanently damaged!

Tolerance ± 1%; error greater than or equal to 10V ± 0.3V; error less than 10V ± 0.10

Input impedance> 100K ohms

Working current red <23mA, green <18mA, blue <13mA

Refresh speed of about 300mS once

Display mode three 0.56 "LED digital tube

Display color red, green, blue optional

Lead length 20cm

Dimensions 48 x 29 x 22 mm, long X wide X thick;

Mounting hole 46 x 27 mm

Net weight 19g

Gross weight 26g

Operating temperature -10 ° ~ 65 °

Status: Stock Available

Regular Price: ৳190 BDT

Discount Price: ৳190 ৳320

Specification

Ultra-low cost, high precision to meet most of the application requirements.

High precision

low starting working voltage, red minimum 4.5V, green minimum 5.0V, blue minimum 5.0V.

with reverse protection, anti-burn.
